English, 18) pwr_led, 19) ci (chassis intrusion, case open) – Intel GA-G1975X User Manual
Page 30
GA-G1975X Motherboard
- 30 -
English
18) PWR_LED
The PWR_LED connector is connected with the system power indicator to indicate whether the
system is on/off. It will blink when the system enters suspend mode.
Pin No.
Definition
1
MPD+
2
MPD-
3
MPD-
1
19) CI (Chassis Intrusion, Case Open)
This 2-pin connector allows your system to detect if the chassis cover is removed. You can check
the "Case Opened" status in BIOS Setup.
Pin No.
Definition
1
Signal
2
GND
1
