Intel® 41210 Serial to Parallel PCI Bridge Design Guide

55

41210 Bridge Customer Reference
Boards

11

This chapter describes the 41210 Bridge Customer Reference Board (CRB).

11.1

Board Stack-up

The proposed layout of the PCB is eight layers with the following stackup:

Signal #1 (Top/Component Side)

Ground Plane: GND

Signal #2

Power Plane

Power Plane

Signal #3

Ground Plane

Signal #4 (Bottom)

The permittivity constant Er = 4.5
