Syn-Tech III P25 Portable Radio
OPERATION MANUAL
680-090-2040
Version 6.0
http://www.midlandradio.com
3
2.3 Installing the Belt Clip
1. Pinch the belt clip mounting bracket
using your thumb and index finger.
2. Align the belt clip mounting bracket
with the slots on the battery.
3. Press the belt clip against the battery
and slide the clip fully into the retaining
slots.
2.4 Charging the Battery
CAUTION
The Li-Ion rechargeable battery should only be charged using
Midland desktop chargers.
To charge the battery:
1. Insert the wall mount adaptor cord into the back of the drop-in charging cradle.
2. Plug the other end of the wall mount adaptor into the appropriate AC power
source.
3. Place the radio into the desktop charger. The metal pads on the radio must
contact the mating pads in the charger.
4. Observe that the red light on the front of the charger glows red to indicate that
the radio is properly seated and the charger is operating in fast charge mode.
5. Allow the batteries to charge for 12 to 15 hours for initial charge.
CAUTION
The charger is only designed to charge the battery, not power the
radio. You can monitor incoming calls while the radio is charging.
However, you should always remove the radio from the charger
before transmitting.
WARNING
The LED on the front of the charger glows green after 4 hours to indicate
the radio is fully charged. However, you should leave your radio in the
charger 12 to 15 hours for initial charge.
WARNING
See troubleshooting near the end of this manual for additional desktop
charger LED alerts.
As you use your radio, the battery level icon will show the battery power
remaining. When the icon shows empty (no bars), it is time to recharge
the battery.
Figure 2.4 – Installing the belt clip
