Chapter 7 Wiring Diagrams and Signal Information
7-383
♦
Outline of DEVE DRIVE ASSY
✧ Motor type: Hybrid stepping motor
✧ Stepping angle:1.8° ± 0.09°
✧ Winding resistance:2.8
Ω
± 10% / phase (25°C)
✧ Exciting sequence:(*: Exciting)
♦
Outline of MAIN DRIVE ASSY
✧ Motor type: Hybrid stepping motor
✧ Stepping angle:1.8° ± 0.09°
✧ Winding resistance:2.1
Ω
± 10% / phase (25°C)
✧ Exciting sequence:(*: Exciting)
Signal line name
Description
DEVE B,DEVE TDB,DEVE A,
DEVE TDA,DA_DEVEMOT
DEVE DRIVE ASSY drive control signal
DEVE_A,DEVE_B,DEVE_XA,DEV
E_XB
DEVE DRIVE ASSY exciting signal
MAIN B,MAIN TDB,MAIN A,
MAIN TDA,DA_MAINMOT
MAIN DRIVE ASSY drive control signal
MAIN_A,MAIN_B,MAIN_XA,MAIN_
XB
MAIN DRIVE ASSY exciting signa
FSR B,FSR TDB,FSR,
FSR TDA,DA_FSRMOT
FUSER DRIVE ASSY drive control signal
FSR_A,FSR_B,FSR_XA,FSR_XB
FUSER DRIVE ASSY exciting signal
DUP B,DUP TDB,DUP A,
DUP TDA,DA_DUPMOT
MOT ASSY DUP drive control signal
DUP_A,DUP_B,DUP_XA,DUP_XB MOT ASSY DUP exciting signal
FAN FSR STOP
FAN FSR drive control signal
FAN FSR LOW
FAN FSR ON(H)+24VDC
FAN FSR ON/OFF control signal
FAN FSR FAIL(H)+3.3VDC
FAN FSR fail detection signal (High: Fail, Low: Normal)
Phase
Step (2 phases)
1
2
3
4
DEVE_A
*
*
DEVE_B
*
*
DEVE_XA
*
*
DEVE_XB
*
*
Phase
Step (2 phases)
1
2
3
4
MAIN_A
*
*
MAIN_B
*
*
MAIN_XA
*
*
MAIN_XB
*
*
