1.3
Getting started
1 COPY light Glows when the machine is in the Copy mode.
2 FAX light Glows when the machine is in the Fax mode.
3 ALARM light Glows when a problem occurs during fax communication,
printing or scanning. The light stays on until the machine prints a Check
Message report.
4 COMM . light Glows when the machine is communicating with another
machine.
5
MEMORY RECEIVE light Glows when the machine is receiving an incoming
fax document into its electronic memory.
6 Soft Keys Shortcut keys. Any function that can be turned on or off can be
programmed into these three keys. If the light above one of these keys glows,
this indicates the setting that s been programmed into it (see page 3.17) is
turned on. These keys are programmed at the factory to turn the following
functions on or off:
Soft key 1: REPORT Press to turn the confirmation report feature on or off
for the next fax transmission.
Soft key 2: MEMORY TRANSMISSION Selects which transmission mode your
fax machine uses, whether Memory transmission or Real time transmission
(see page 2.3).
Soft key 3: MONITOR / CALL Turns the monitor speaker off or on. When it s on,
it allows you to hear the call you re making. When using this feature, you can
only hear the communication taking place. You cannot be heard unless you
use a handset (optional). When sending a fax, this key also activates the call
request feature.
7
REDIAL / PAUSE Redials the last number you dialed. In certain operations, it
also produces a special pause character which can be useful when dialing
long-distance numbers.
8 DIALING OPTIONS Press this to insert special symbols into telephone num-
bers (see page 3.1).
9 BROADCAST Press to send a broadcast fax (sending the same document to
more than one location).
10 GROUP Press this to set up a fax transmission to a call group, a set of fax
numbers which will receive the same document in one fax operation.
11 ADVANCED FUNCTIONS
In Fax mode: Chooses from following several fax options delayed transmis-
sion, Polling, F-Code transmission, F-Code polling and Batch transmission.
Or, in Copy mode: Chooses from following copy options Nega/Posi copy,
Combine copy (only for MFX-1600) or Ultra copy (only for MFX-1600).
12 REVIEW COMMANDS Press to review pending fax commands or to view a
brief description of delayed commands.
Control Panel Overview
1 2 3 4 5 6 7 8 9 10 11 12 13 14
15 16 17 18 19 20 21 22 23 24 25 26 27
28
