66
ENGLISH
AUX2 INPUT
If you don’t need to connect 7.1 Ch. input terminals
with multi channel decoder,
L(front left) and R (front right) inputs terminals are
available as AUX2 input.
In this case, You can connect additional audio source
to AUX2 as other audio input terminals.
STANDBY
PHONES
INPUT SELECTOR
AV SURROUND RECEIVER SR8002
MEN
PURE DIRECT
THX
7.1CH I
MODE
AUTO
MULTI
PURE DIRECT
SURROUND
DSD
POWER ON/OFF
DISP
MULTI
AUTO
SLEEP
SURR
AUTO
VIDEO ON/OFF
When no video signal is connected to the unit or
a DVD, etc., is connected directly to your TV, the
unnecessary video circuit can be turned off by
selecting the “VIDEO OFF” setting.
To select video off, press the AMP button and press
the > button until PAGE 4 is displayed. Press the V-
OFF button.
ONES
UND RECEIVER SR8002
M-DAX
ENTER
MENU
PURE DIRECT
THX
7.1CH INPUT
MODE
AUTO
MULTI
A/B
T-MODE
MEMORY
CLEAR
DISPLAY
EXIT
SPEAKERS
BAND
MIC
PURE DIRECT
SURROUND
SPEAKER
MULTI
DSD
L
C
R
SL
S
SR
LFE
DIGITAL
SURROUND
V-OFF
DISP
MULTI
AUTO
TUNED
ST
SPKR A B
NIGHT
PEAK
ANALOG
DIGITAL
ATT
SLEEP
SURR
DIRECT
AUTO
DISC 6.1
MT X 6.1
EQ
PCM
AAC
AMP
AUX2
AUX1
TAPE
TUNER
CD
CD-R
MD
1
2
LIGHT
Learning Remote Controller
RC8001SR
AMP
D4
D5
D2
M
D1
D3
D5
VOL
CH
USE
PAGE
1 2 3
4
D4
TV AUTO ON/OFF FUNCTION
This function allows the component connected to the
TV-VIDEO in jack to control the power (ON/OFF) to
the unit.
AUTO POWER ON
1.
Be sure the TV auto mode is ENABLED. (Refer
to page 53:)
2.
Connect your TV TUNER (etc) to the TV-
VIDEO in terminal. Be sure to connect the
VIDEO input.
3.
Turn OFF the power to the TV TUNER and the
unit.
4.
Turn ON the TV TUNER and tune in a receivable
station.
5.
When the station is received, this unit turns ON
and TV is selected automatically.
AUTO POWER OFF
1.
In the above situation, turn the TV TUNER OFF
or select a channel that does not contain any
broadcast.
2.
The power to the unit switches to STANDBY
after approx. 5 minutes.
Notes:
• AUTO POWER OFF is canceled if this unit is set to
a source other than TV.
The function reactivates when TV is selected again.
• Some TV broadcasts may cause the TV AUTO
FUNCTION to turn ON.
• The S-Video terminal does not support “TV AUTO
ON/OFF” function.
LIP.SYNC
Depending on the image device (TV, monitor,
projector, etc.) connected to the unit a time lag can
occur between image signal processing and audio
signal processing. Though minor, this time lag can
interfere with movie and music enjoyment. The LIP.
SYNC feature delays the audio signal with respect to
the image signal output from the SR7001 to correct
the time lag between the sound and image. It can be
operated with the “LIP.SYNC” and
1 and 2 cursor
buttons of the remote controller. Set the remote
controller to the AMP mode before operating the
LIP.SYNC feature. The initial setting is OFF (0 ms).
The time lag can be adjusted in 10 ms steps up to
200 ms.
Watch the picture on the image device (i.e., TV,
monitor, projector, etc.) as you adjust the time lag.
2
3
1
5
6
4
8
0
9
7
MEMO
CLEAR
OK
VOL
CH
PREV
MUTE
MENU
EXIT
GUIDE
TEST
CH.SEL
LIP.SYNC
SURR
7.1CH
ATT
SPK-AB
DISP
OSD
THX
SLEEP
GUIDE
LIP.SYNC
Note:
• The LIP.SYSNC feature turns OFF (0 ms) in
the SOURCE/PURE DIRECT mode. When the
SOURCE/PURE DIRECT mode is deactivated, the
set value of the LIP.SYSNC feature is automatically
restored.
• Even if you do not correct the time lag manually this
way, audio and video are automatically synchronized
when the unit is connected to TV or Projectors
supporting Auto Lipsync Correction in HDMI 1.3a.
For instructions on Auto Lipsync Correction, see
page 54.
DUAL BACKUP MEMORY
The unit stores settings information in nonvolatile
memory even when the main power supply is turned
off. Using the Dual Backup Memory function, you
can write settings information to another memory
area to back up saved settings for recovery anytime
as needed.
BACKUP
Set up the unit in the state for which you want to
store the settings. Hold the MEMORY and ENTER
buttons on the front panel simultaneously for at least
3 seconds.
DIGITAL
VIDEO
S-VIDEO
AUX 1 INPUT
VOLUME
DOWN
M-DAX
MENU
7.1CH INPUT
MULTI
A/B
T-MODE
MEMORY
CLEAR
DISPLAY
EXIT
SPEAKERS
BAND
MIC
SPEAKER
MULTI
ENTER
L
C
R
SL
S
SR
LFE
DIGITAL
SURROUND
V-OFF
ULTI
AUTO
TUNED
ST
SPKR A B
NIGHT
PEAK
ANALOG
DIGITAL
ATT
SURR
DIRECT
AUTO
DISC 6.1
MT X 6.1
EQ
PCM
AAC
“MEMORY SAVING” is displayed and the unit’s
settings are saved. The stored settings information
is retained until Dual Backup Memory is used again
and the information is overwritten.
M E M O R Y S A V I N G
Note:
• The following settings values cannot be backed
up.
• Main Room Volume
• Multi Room Volume
• Multi Speaker Room Volume
RECOVERY OF MEMORY
Recover backed up settings as follows.
Hold the MEMORY and MENU buttons on the front
panel simultaneously for at least 3 seconds.
DIGITAL
DOWN
M-DAX
MENU
PURE DIRECT
THX
7.1CH INPUT
MODE
AUTO
MULTI
A/B
T-MODE
MEMORY
CLEAR
DISPLAY
EXIT
SPEAKERS
BAND
MIC
URE DIRECT
SURROUND
SPEAKER
MULTI
DSD
ENTER
L
C
R
SL
S
SR
LFE
DIGITAL
SURROUND
V-OFF
DISP
MULTI
AUTO
TUNED
ST
SPKR A B
NIGHT
PEAK
ANALOG
DIGITAL
ATT
SLEEP
SURR
DIRECT
AUTO
DISC 6.1
MT X 6.1
EQ
PCM
AAC
“MEMORY LOAD” is displayed and the unit’s stored
settings are reapplied.
The unit temporarily enters standby mode. If there is
no backup data, “NO BACKUP” is displayed and no
data is recovered.
M E M O R Y L O A D
N O B A C K U P
Note:
• Because the following settings values are
not backed up, each Volume value is set to
Minimum.
• Main Room Volume
• Multi Room Volume
• Multi Speaker Volume
