ENGLISH
22
SETTING THE MACRO TIMER
Setting the macro timer enables the macro program
to automatically turn the power for a device on or off
or perform other operations.
In the settings, you can select to execute the macro
timer everyday or only once.
Be sure to set the clock to the correct time before
using the timer. The macro timer can only be set for
one program a day.
This example shows how to use the timer only once
at 20:35 to execute a macro programmed to M-01.
2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
5 6
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
1. Hold down the M button for three seconds or
more.
The menu is displayed.
2. Press the > button to display the third page
TIMER menu.
3. Press the D2 (ONCE?) direct button.
The M-TMR menu is displayed on the LCD.
• To cancel timer operation, press CANCEL.
4. Press the D1 (M-01) direct button .
The time which is set previously is displayed.
5. Press the 2 and 0 numeric button to set the
hour indicator to 20.
6. Press the 3 and 5 numeric button to set the
minute indicator to 35.
7. Press the OK cursor button.
This fi nalizes the time.
8. To exit, press the M button.
To cancel the macro timer, return to the TIMER
menu and press the D5 (CANCEL) and then press
D1 (M-01).
EXECUTING THE MACRO TIMER
The macro program starts when the time that was
set is reached. The TIMER
indicator lights up
whenever the macro timer is activated.
Note:
• To execute the macro timer, place the remote
controller facing the infrared sensor of the device
to be operated. If the remote controller is not in
a suitable position, it may not operate the device
properly.
CLONE MODE
CREATING COPIES USING CLONE MODE
All of the codes programmed to the RC8001SR remote
controller can be copied to another RC8001SR using
a few simple operations.
• The remote controller can copy the entire contents
or the contents for specifi c source buttons.
• When copying the entire contents, all programmed
codes, modifi ed names, programmed macros, and
signal transmission intervals are copied.
When copying the contents for source buttons, the
programmed codes and modifi ed names are copied.
Note:
• The clone function can only be used for copying
when using the same model (RC8001SR) for both
the transmitting and receiving remote controller.
COPYING ENTIRE CONTENTS
3 4 9
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
5 6 9
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
1. Place the receiver sensor of the receiving
remote control (top) so that it is facing the
transmitter of the transmitting remote control
(top) at a distance of about 5 cm (2 inches).
2. Hold down the M button of the transmitting
remote controller for three seconds or more.
The menu is displayed.
3. Press the > button to display the fourth page
CLONE menu.
4. Press the D3 (TX) direct button.
The transmitting side is now ready.
5. Hold down the M button of the receiving remote
controller for three seconds or more.
The menu is displayed.
6. Press the > button to display the fourth page
CLONE menu.
7. Press the D1 (RX) direct button.
The receiving side is now ready.
8. Press the OK cursor button on the receiving
remote controller.
9. Press the OK cursor button on the transmitting
remote controller.
When copying is started, the bar indicators on both
LCDs start to move from the left to the right.
• When the copying operation is completed,
TX OK is displayed on the LCD of the
transmitting remote controller, and RX OK
is displayed on the LCD of the receiving
remote controller.
• Do not touch either of the remote controllers
during the copying operation. Doing so
could cause copying to fail.
• If the copying fails in the middle of the
copying process, RX ERROR is displayed
on the receiving remote controller. Check
and perform steps 1 to 7 again.
• Copying takes about three minutes to
complete when the transmitting remote
controller has been programmed to 100%
capacity.
10. Once copying is completed, press the M button
on both remote controllers.
COPYING BY SOURCE
The 12 sources can be copied on a source by source
basis. You can select from up to 12 source types.
6 7 8
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
LEARN
NAME
MACRO
USE PAGE 1 2 3 4
1. Place the receiver sensor of the receiving
remote control (top) so that it is facing the
transmitter of the transmitting remote control
(top) at a distance of about 5 cm (2 inches).
2. Hold down the M button of the transmitting
remote controller for three seconds or more.
The menu is displayed.
3. Press the > button to display the fourth page
CLONE menu.
4. Press the D3 (TX) direct button.
The transmitting side is now ready.
5. Hold down the M button of the receiving remote
controller for three seconds or more.
6. Press the > button to display the fourth page
CLONE menu.
7. Press the D2 (RX-S) direct button.
8. Press the source button to be copied.
The receiving side is now ready.
The name of the source which was pressed is
displayed on the LCD.
• Each time the source button is pressed, the
name is displayed on the LCD.
9. Press the OK cursor button on the receiving
remote controller.
10. Press the OK cursor button on the transmitting
remote controller.
When copying is started, the bar indicators on both
LCDs start to move from the left to the right.
• When the copying operation is completed,
TX OK is displayed on the LCD of the
transmitting remote controller, and RX OK
is displayed on the LCD of the receiving
remote controller.
• Do not touch either of the remote controllers
during the copying operation. Doing so
could cause copying to fail.
• If the copying fails in the middle of the
copying process, ERROR is displayed on
the remote controller.
Check and perform steps 1 to 7 again.
