8 78D0011
WDV Series Gas Fireplace
72” Minimum
Ceiling
12” Max.
Depth
2 1 /
2
” Max Depth
6” Min.
From Opening
12” Min.
From Opening
6” Min.
FP2421
mantel clearances
clearances
Mantel clearances
nOte: the combustible area above the facing must not protrude more than 3/4" from the
facing. If it does, it is considered a mantel and must meet the mantel requirements listed in
this manual.
Figure 4 -
Ceiling and Sidewall Clearances
6 ”
5 ”
3 ”
4 56O ”
45°
1 ”
3 56O ”
FP2423
mantel leg
156O”
256O”
FP2423
Side of Fire-
place Opening
Figure 5 -
Mantel clearances
top View
clearances tO cOMBustIBles
Follow these instructions carefully to ensure safe installation. Failure to
follow instructions exactly can create a fire hazard.
the appliance cannot be installed on a carpet, tile or other combustible
material other than wood flooring. If installed on carpet or vinyl flooring,
the appliance shall be installed on a metal, wood or noncombustible
material panel extending full width and depth of the appliance.
W
arn
In
G
FP2421
9"
12"
6"
12"
6"
2 1 /
2
"
FP2422
mantel clearances
Wall
Stud
Insulation
Board
Standoff
Top of Fireplace
Opening
FP2422
side View
