6 78D0011
WDV Series Gas Fireplace FIreplace & FraMInG DIMensIOns
W
arn
In
G
Do not fill spaces around firebox with
insulation or other materials. this could
cause a fire.
W
arn
In
G
unit framing is to be rectangular front to
back. Failure to do so will cause fire and
damage to property.
1/2” or
5/8”
2356M” (591 mm)
Min. Rough Opening Width
(466 ” (1184 mm)
17(6 ”
(454 mm)
186QE”
(462 mm)
Minimum Rough
Opening
Depth
40” (1016 mm)
3656 ”
(918 mm)
17(6 ”
(454 mm)
296QE”
(751 mm)
35(6QE”
(900 mm)
356O”
(89 mm)
156O”
(38 mm)
136M” (349 mm)
56M”
(146 mm)
6”
(152 mm)
81
(6
” (2080 mm)
57 (6 ” (1470 mm)
41”
(1041 mm)
57
(6
” (1470 mm)
356 ”
(905 mm)
Min. Rough
Opening
Height
780012
DVW WDV dims
4656 ” (1172 mm)
86QE”
(211 mm)
Required Noncombustible
Material Area
Figure 2 -
Fireplace and Framing Dimensions
