78D0011 43
WDV Series Gas Fireplace replaceMent parts
Vent cOMpOnents FOr 5" x 8"
current Old
simpson simpson
Duravent Duravent
qty./ or Mhsc or Mhsc selkirk
Item Box Description part no. part no. part no.
1 1 Horizontal High Wind Termination Cap 58DVA-HC 1285 5DT-HC
1 1 Horizontal Termination Cap Built-In Vinyl Siding Standoff, BHS8TK
Heat Deflector, Firestop, 90° Elbow and Adjustable
Pipe 11" to 14 5 /
8
"
1 1 Horizontal Termination Cap w/Built-In Vinyl Siding Standoff, BHSF8TKA
Heat Deflector, Firestop, Flexible Pipe 20" to 48", Adapter
1 8 Horizontal Termination w/ 1" Firestop BHRST/8
2 1 Vertical Termination 58DVA-VC 1280 5DT-VC
3 4 6" Pipe Length 58DVA-06 1208 5DT-06
3 4 9" Pipe Length 58DVA-09 1207 5DT-09
3 4 12" Pipe Length 58DVA-12 1206 5DT-12
3 4 24" Pipe Length 58DVA-24 1204 5DT-24
3 4 36" Pipe Length 58DVA-36 1203 5DT-36
3 4 48" Pipe Length 58DVA-48 1202 5DT-48
4 4 8 1 /
2
" Pipe Extension 58DVA-08A -- 5DT-AJ
4 4 16" Pipe Extension 58DVA-16A -- --
5 4 45° Elbow 58DVA-E45 1245 5DT-EL45
5 4 45° Swivel Elbow -- -- 5DT-EL45
6 4 90° Elbow 58DVA-E90 1290 5DT-EL90S
6 4 90° Swivel Elbow -- 1290G 5DT-EL90S
7 6 Flashing, 0/12 to 6/12 Roof Pitch 58DVA-F6 1243 5DT-AF6
7 Steep Roof Flashing 58DVA-F12 1243S --
8 6 Storm Collar 58DVA-SC 1253 5DT-SC
9 4 Firestop 58DVA-FS 1263 5DT-FS
9 1 1" Firestop 58DVA-FS --
10 1 Vinyl Siding Standoff 58DVA-VSS 1250 5DT-VS
11 Attic Insulation Shield (not shown) 58DVA-IS -- --
12 8 Flex Adapter Starter (not shown) DVF8A/8 -- --
