MSI FUZZY 945GME1 User Manual
Page 29
2-11
Hardware Setup
Important
If you install two IDE devices on the same cable, you must config-
ure the drives separately to master / slave mode by set ting
jumpers. Refer to IDE device
’s documentation supplied by the
vendors for jumper setting instructions.
Serial ATAII Connector: SATA1, SATA2
This connector is a high-speed Serial ATA interface port. Each connector can
connect to one Serial ATA device.
Please do not fold the Serial ATA cable into 90-degree angle.
Otherwise, data loss may occur during transmission.
Important
SATA1
SATA2
