2-7
Hardware Setup
ATX 20-Pin Power Connector: ATX1
This connector allows you to connect to an power supply. To connect to the
power supply, make sure the plug of the power supply is inserted in the proper
orientation and the pins are aligned. Then push down the power supply firmly
into the connector.
Power Supply
ATX1
10 20
1 11
SIGNAL
3.3V
3.3V
GND
5V
GND
5V
GND
PW_OK
5V_SB
12V
Pin Definition
PIN
1
2
3
4
5
6
7
8
9
10
PIN
11
12
13
14
15
16
17
18
19
20
PINSIGNAL
3.3V
-12V
GND
PS_ON
GND
GND
GND
-5V
5V
5V
ATX 12V Power Connector: JPW1
This 12V power connector is used to provide power to the CPU.
PIN
1
2
3
4
Pin Definition
SIGNAL
GND
GND
12V
12V
JPW1
1
3
2
4
1. Make sure that all the connectors are connected to proper ATX
power supplies to ensure stable operation of the mainboard.
2. Power supply of 130 watts (and above) is highly recommended for
system stability.
3. ATX 12V power connection should be greater than 6A.
Important
