2-9
Hardware Setup
Audio Port Connectors
These audio connectors are used for audio devices. You can differentiate the
color of the audio jacks for different audio sound effects.
Line-In (Blue) - Line In / Side-Surround Out in 5.1 channel mode, is
used for external CD player, tapeplayer or other audio devices.
Line-Out (Green) - Line Out, is a connector for speakers or
headphones.
Mic (Pink) - Mic, is a connector for microphones.
LAN
The standard RJ-45 LAN jack is for connection to the Local Area Network
(LAN). You can connect a network cable to it.
Link Indicator
Activity Indicator
Left
Condition
Off
On (steady state)
On (brighter & pulsing)
On
On
Orange
Orange
Green
Right
LAN link is not established.
LAN link is established.
The computer is communicating with another computer on the LAN.
10 Mbit/sec data rate is selected.
Off
100 Mbit/sec data rate is selected.
1000 Mbit/sec data rate is selected.
LED
Color
LED State
