14
(A)
Open the Stand
and place on flat surface
(C)
Align the Stand supports to
the depressions on the pan
(B)
Orient the Saw to the
Stand
(D)
Sit the Water Pan on top of
the Stand Supports
(E)
Verify that the saw is stable
in place
OPTIONAL STAND
1. The MK-370EXP weighs approximately thirty-three (33) pounds; use care when lifting.
2. Never lift the MK-370EXP with water in the Water Pan.
CAUTION
MK-370EXP UNIVERSAL STAND ASSEMBLY
TRANSPORT
The MK-370EXP is designed with a rigid frame and removable Cutting Head making the saw easily
transportable. To lift the saw, grasp the front and back of the frame at the lift points shown below.
Cutting
Head
Lift Point
Lift Point
1. The MK-370EXP weighs approximately thirty-three (33) pounds; use care when transporting.
2. Never transport the MK-370EXP with water in the Water Pan.
CAUTION
If a stand was not included with your saw, you have the option of purchasing one (part# 160131-MK)
