Monessen Hearth MJ27NR - Manual (Page 27)

86D0024 27
ANDIRON and ROCK INSTALLATION
ANDIRON INSTALLATION
2, Andirons
2, Brackets
2, 2 1 /
4
Bolts
Assembly Instructions
1. Affix bracket to andiron using 2
1 /
4
bolts. Figure 29
2. The andiron bracket clips over the lower horizontal grate bar. Figure 30
3. The left andiron goes to the left of the large knot on the front left log. The right andiron
will adjust left to right to center equally in fireplace.
PLACING ThE DECORATIvE ROCk
FP2012
andiron to bracket
Bracket
FP2012
Figure 29 - Attach Bracket to Andiron
FP2013
attach andirons to grate
Figure 30 - Attach Andirons to Grate
FP2013
CAUTION
DO NOT sprinkle volcanic rock on the logs, around the pilot, or on or near burners. This
may cause sooting. Place volcanic rock only on the floor of the fireplace.
During initial operation of the new heater, new burning logs and/or rock wool will give off
a paper burning smell and orange flames will be present. Simply open the windows for a
few hours to vent the odor.
