Electrical wiring (millivolt), Caution, Fp2009 mj wiring diagram – Monessen Hearth MJ27NR User Manual
Page 21
86D0024
21
FP2009
MJ wiring diagram
FP2009
Motor
ELECTRICAL WIRING (MILLIVOLT)
The Millivolt valve is a self-powered combination gas control
ThAT DOES NOT REquIRE 110 vAC TO OPER-
ATE.
Figure 16 - Wiring Diagram
CAUTION
Label all wires prior to disconnection when servicing controls.
wiring errors can cause improper and dangerous operation. verify
proper operation after servicing.
ODS Pilot
Millivolt
Valve
TH = 3
TP = 1
TP/TH = 2
