Galaxy 4000 – MGE UPS Systems 40-75KVA User Manual
Page 38
Figure 4-1: Galaxy 4000 Device Locations.
Galaxy 4000
Operation
4 — 2
86-173010-00 A00
COMMUNICATION
CARD PORTS
Q1
INPUT SWITCH
Q3BP
MAINTENANCE
BYPASS SWITCH
(optional)
EMERGENCY
POWER OFF
Q4S
BYPASS SWITCH
Q5N
OUTPUT
CIRCUIT BREAKER
CUSTOMER ACCESS
QUALIFIED TECHNICIAN ACCESS ONLY
ELECTRICAL
INTERLOCK
(optional)
ACCESSORIES
OUTLETS
