Marathon Monitors Inc.
AACC 2000 Carbon Nov. 1, 1997
75
Name Description Values Meaning
AA AA
Alarm relay configuration
id
Identity
rELy
Relay output
Func
Function
nonE
No function
dIG
Digital output
SEnS
Digital output sense
nor
Normal (output energises when
TRUE, e.g. program events)
inv
Inverted (output de-energises
when TRUE, e.g. alarms)
The following digital events appear after ‘
SEnS’. Any one, or more, of the events can be
combined on to the output (see Fig. 6-2) by selecting ‘
YES’ in the lower readout.
1 - - - Alarm 1 active
YES / no (- - -) = alarm type (e.g. FSL).
2 - - - Alarm 2 active
YES / no If an alarm has not been
configured
3 - - - Alarm 3 active
YES / no in ‘AL ConF’ list, then display
will
4 - - - Alarm 4 active
YES / no differ:- e.g. Alarm 1 = ‘AL 1’.
mAn
Controller in manual mode
YES / no
Sbr
Sensor break
YES / no
SPAn
PV out of range
YES / no
Lbr
Loop break
YES / no
Ld.F
Load failure alarm
YES / no
tunE
Tuning in progress
YES / no
dc.F
Voltage output open circuit, or mA
output open circuit
YES / no
rmt.F
module connection open circuit
YES / no
iP1.F
Input 1 Failure
IMP
Impedance test in progress
burn
Probe burn off in progress
VERi
Probe verification in progress
VFLT
Verification Fault
PFLT
Probe Fault
nw.AL
New Alarm has occurred
YES / no
End
End of setpoint rate limit, or end of
program
YES / no
SYnc
Program Synchronisation active
YES / no
