Marathon Computer AACC 2000 - Manual (Page 38)

Marathon Monitors Inc.
AACC 2000 Carbon Nov. 1, 1997
38
Name Description
User User
User list
n1 n1 user parameter #1
n2 n2 user parameter #2
n3 n3 user parameter #3
n4 n4 user parameter #4
n5-15 n5-15
user parameter #5 - 15
Name Description
AL AL Alarm list
1 1 - - - - - - Alarm 1 setpoint value
2 2 - - - - - - Alarm 2 setpoint value
3 3 - - - - - - Alarm 3 setpoint value
4 4 - - - - - - Alarm 4 setpoint value
In place of dashes, the last three characters indicate the alarm type. See alarm types
table:
HY HY 1 1
Alarm 1 Hysteresis (display units)
HY HY 2 2
Alarm 2 Hysteresis (display units)
HY HY 3 3
Alarm 3 Hysteresis (display units)
HY HY 4 4
Alarm 4 Hysteresis (display units)
Lb Lb t t
Loop Break Time in minutes
diAG diAG
Enable Diagnostic alarms ‘
no’ / ‘YES’
Alarm types table
-FSL -FSL
PV Full scale low alarm
-FSH -FSH
PV Full scale high alarm
- -dEv dEv
PV Deviation band alarm
- -dHi dHi
PV Deviation high alarm
- -dLo dLo
PV Deviation low alarm
- -LCr LCr
Load Current low alarm
- -HCr HCr
Load Current high alarm
-FL2 -FL2
Input 2 Full Scale low alarm
-FH2 -FH2
Input 2 Full Scale high alarm
-LOP -LOP
Working Output low alarm
-HOP -HOP
Working Output high alarm
-LSP -LSP
Working Setpoint low alarm
-HSP -HSP
Working Setpoint high alarm
4rAt 4rAt
Rate of change alarm (AL 4 only)
Atun Atun
Autotune list
