Marathon Monitors Inc.
AACC 2000 Carbon Nov. 1, 1997
71
gsch
Gain schedule enable
no
yes
Disabled
Enabled
pV
pV
Process value config
unit
Inststrument units
0
C
Celsius
0
F
Farenheit
0
k
Kelvin
dec.p
Decimal places in the
none
Display units blanked
displayed value
nnnn
nnn.n
nn.nn
None
One
Two
rng.l
Range low
Low range limit. Also setpoint limit for
alarms and programmers
rng.h
Range high
High range limit. Also setpoint limit for
alarms and programmers
Name
Description
Values
Meaning
iP
iP
Input configuration
inPt
Input type
J.tc
J thermocouple
k.tc
K thermocouple
L.tc
L thermocouple
r.tc
R thermocouple (Pt/Pt13%Rh)
b.tc
B thermocouple (Pt30%Rh/Pt6%Rh)
n.tc
N thermocouple
t.tc
T thermocouple
S.tc
S thermocouple (Pt/Pt10%Rh)
PL 2
PL 2 thermocouple
C.tc
Custom downloaded t/c (default = type
C)
rtd
100
Ω
platinum resistance thermometer
mV
Linear millivolt
voLt
Linear voltage
mA
Linear milliamps
Sr V
Square root volts
Sr A
Square root milliamps
* see
“CUST” List.
mV.C
8-point millivolt custom linearisation
*
V.C
8-point Voltage custom linearisation
*
mA.C
8-point milliamp custom linearisation
*
Name
Description
Values
Meaning
CJC
Cold Junction
Auto
Automatic internal compensation
Compensation
0
o
C
0
o
C external reference
45
o
C
45
o
C external reference
50
o
C
50
o
C external reference
OFF
No cold junction compensation
imp
Sensor Break Impedance
Off
Disabled (only with linear inputs)
Auto
Factory set
Hi
Impedance of input > 5K
Ω
Hi.Hi
Impedance of input > 15K
Ω
