HDV Series Direct Vent Gas Fireplace
60 56D3048
RePlACeMeNt PARtS
For more information about, or instructions for, the venting components referenced above, please contact
the component manufaturer:
Selkirk Corporation: www. selkirkcorp.com or 800-99-8368
Simpson Duravent: www. duravent.com or 800-835-449
VENT COMPONENTS FOR 5" X 8"
Current Old
Simpson Simpson
Duravent Duravent
Qty./ or MHSC or MHSC Selkirk
Item Box Description Part no. Part no. Part no.
1 1 Horizontal High Wind Termination Cap 58DVA-HC 185 5DT-HC
1 1 Horizontal Termination Cap w/Built-In Vinyl Siding BHR8TK9
Standoff Heat Deflector, Firestop and Adjustable
Pipe 11" to 14 5 /
8
"
1 1 Horizontal Termination Cap Built-In Vinyl Siding Standoff, BHS8TK
Heat Deflector, Firestop, 90° Elbow and Adjustable
Pipe 11" to 14 5 /
8
"
1 1 Horizontal Termination Cap w/Built-In Vinyl Siding Standoff, BHSF8TKA
Heat Deflector, Firestop, Flexible Pipe 0" to 48", Adapter
1 8 Horizontal Termination w/ 1" Firestop BHRST/8
1 Vertical Termination *see below *see below 5DT-VC
3 4 6" Pipe Length 58DVA-06 108 5DT-06
3 4 9" Pipe Length 58DVA-09 107 5DT-09
3 4 1" Pipe Length 58DVA-1 106 5DT-1
3 4 4" Pipe Length 58DVA-4 104 5DT-4
3 4 36" Pipe Length 58DVA-36 103 5DT-36
3 4 48" Pipe Length 58DVA-48 10 5DT-48
4 4 8 1 / " Pipe Extension 58DVA-08A -- 5DT-AJ
4 4 16" Pipe Extension 58DVA-16A -- --
5 4 45° Elbow 58DVA-E45 145 5DT-EL45
5 4 45° Swivel Elbow -- -- 5DT-EL45
6 4 90° Elbow 58DVA-E90 190 5DT-EL90S
6 4 90° Swivel Elbow -- 190G 5DT-EL90S
7 6 Flashing, 0/1 to 6/1 Roof Pitch 58DVA-F6 143 5DT-AF6
7 Steep Roof Flashing 58DVA-F1 143S --
8 6 Storm Collar 58DVA-SC 153 5DT-SC
9 4 Firestop 58DVA-FS 163 5DT-FS
9 3" Firestop FS38 FS38 --
10 1 Vinyl Siding Standoff 58DVA-VSS 150 5DT-VS
11 Attic Insulation Shield (not shown) 58DVA-IS -- --
1 8 Flex Adapter Starter (not shown) DVFF8A/8 -- --
13 1 Reducer - 5 x 8 to 4 x 6 5 /
8
(not shown) 1DA 1DA --
* Simpson Duravent 58DV-VC180 vertical cap cannot be
used with this fireplace.
