HDV Series Direct Vent Gas Fireplace
46
56D3048
loG INStAllAtIoN
LG693
HDV log final position
Air Space
Rock Wool
LG693
Figure 66 -
All Logs on Burner with Rock Wool
1.Cover any exposed burner surface with
rock wool. For best flame and glow, do not
block air space between burners and logs
with rock wool. Figures 66 and 67
LG694
HDV logs top view
Rock Wool
Figure 67 -
Rock Wool Placement after Logs are All
Logs are Placed (Top View)
LG694
