HDV Series Direct Vent Gas Fireplace
56
56D3048
SIGNAtuRe CoMMAND SySteM
Ref.
Description
qty.
HDV500NSC
HDV500PSC
1.
Gas Valve Assy.
1
80D0001
80D000
.
Pilot Assy.
1
80D0039
80D0040
3.
Control Box
1
80D0018
80D0019
4.
Command Center
1
80D0005
80D0005
5a.
Valve/Tee Tube
1
56D3045
56D3045
5b.
Front Burner Tube
1
56D3046
56D3046
5c.
Rear Burner Tube
1
56D3047
56D3047
6.
Flex Hose w/ Shutoff Valve
1
69D0030
69D0030
7a.
Front Injector
1
56D3059
6D3005
7b.
Rear Injector
1
6D3003
0H3143
8a.
Front Burner Assy.
1
56D3051
56D3051
8b.
Rear Burner Assy.
1
56D305
56D305
9.
Venturi
1
45D0006
45D0006
10.
Wire Valve Control (not shown)
1
80D0010
80D0010
10.
Wire Command Ctr. Control Box ' (not shown)
1
80D0008
80D0008
Accessories
13.
Hand Held Remote Control
RMSC
14.
Hand Held Remote Control w/ Hi/Lo & T-stat
RTSC
15.
Hand Held Remote Control w/ Optional Light, Auxiliary & Blower Control
RFSC
16.
SCS Wall Mount Extension Kit (15' wire, rough-in box, wall cover) (not shown)
SCSWEK
17.
SCS AC Module (converted battery system to AC power)
SCSADM
Fuel Conversion Kits - Signature Command System
Natural Gas to lP
HDV500
Kit #HDV500CKPS
lP to Natural Gas
HDV500
Kit #HDV500CKNS
RePlACeMeNt PARtS
