Alarm relay configuration tab, Comms module 1 configuration tab, Comms module 2 configuration tab – MITSUBISHI ELECTRIC 2408f User Manual
Page 29: Output 1a configuration tab, Output 1b configuration tab, Output 1c configuration tab
Tag Addresses 2408
f
& 2404
f
PROFIBUS Communications Handbook
8-10 2408
f
& 2404
f
PROFIBUS Communications Handbook
AA
Display
Alarm Relay
Configuration Tab
Tag
Address
Parameter Description
O
O
Module identity
12480
9.
9.
Module function
0: None
1: Digital
2: Heat (2208/04 only)
3: Cool (2208/04 only)
12483
.
.
Sense of output
0: Normal
1: Inverted
12489
Summary of AA configuration
12486
Program summary OP AA
configuration
12503
HA
Display
Comms Module 1
Configuration Tab
Tag
Address
Parameter Description
5
5
Comms Resolution
0: Full
1: Integer
12550
JA
Display
Comms Module 2
Configuration Tab
Tag
Address
Parameter Description
O
O
Module Identity
0: None
8: PDSIO output
9: PDSIO input
12608
;)D)
;)D)
Retransmitted Low Scalar
12623
;)D#
;)D#
Retransmitted High Scalar
12622
9.
9.
Module Function
For
O
=
1
128: None
129: PDSIO SP retransmission
130: PDSIO PV retransmission
131: PDSIO OP retransmission
133: PDSIO SP retrans. no
holdback
For
O
=
0O
96: None
97: PDSIO setpoint input
1A
Display
Output 1A
Configuration Tab
Tag
Address
Parameter Description
O
O
Module identity
0: None
1: Relay output
2: DC output non-isolated
3: Logic/PDSIO output
4: Logic input
5: Triac output
10: Error/Bad module
11: DC retransmission
12: DC output isolated
12672
9.
9.
Module function
For
O
=
5)@ )/!
or
5
12675
0: None
1: Digital output
2: Heating output
3: Cooling output
4: Open motorised valve
10: PDSIO mode 1 heating
11: PDSIO mode 2 heating
For
O
=
D5
or
D0
16: None
17: Heating output
18: Cooling output
19: Retransmission of PV
20: Retransmission of SP
21: Retransmission of error
22: Retransmission of OP power
For
O
=
)/!DO
Use the enumerators in LA Config.
list
;)D)
;)D)
% PID or Retran value giving min.
o/p
12687
;)D#
;)D#
% PID or Retran value giving max.
o/p
12686
9.O6
9.O6
Units
1: Volts
2: mA
12684
96D)
96D)
Minimum electrical output
12689
96D#
96D#
Maximum electrical output
12688
.
.
Sense of output
0: Normal
1: Inverted
12681
Summary output 1A configuration
12678
DC output 1A telemetry parameter
12694
Program summary output 1A
config
12695
1B
Display
Output 1B
Configuration Tab
Tag
Address
Parameter Description
O
O
Module 1B identity
12673
9.
9.
Module 1B function
12676
.
.
Sense of output (nor/inv as1A)
12682
Summary of 1B configuration
12679
Summary program O/P 1B config.
12696
1C
Display
Output 1C
Configuration Tab
Tag
Address
Parameter Description
O
O
Module 1C identity
12674
9.
9.
Module 1C function
12677
;)D)
;)D)
Module 1C value giving min output
12699
;)D#
;)D#
Module 1C value giving max output
12698
96D)
96D)
Module 1C Minimum electrical
output
12701
96D#
96D#
Module 1C Maximum electrical
output
12700
.
.
Sense of output (nor/inv as 1A)
12683
Summary of 1C configuration
12680
Summary program O/P 1C config.
12697
