Tag Addresses 2408 f & 2404 f PROFIBUS Communications Handbook
8-6 2408 f & 2404 f PROFIBUS Communications Handbook
Controller Information Tab Tag
Display Parameter Description Addres
s
O0 O0 Configuration of lower readout
display
0: Standard
1: Load current
2: Output power
3: Status
4: Program time
5: None
6: Valve position
7: Process value 2
8: Ratio setpoint
9: Selected program number
10: Remote setpoint
106
)/!D) )/!D) PV minimum 134
)/!D# )/!D# PV maximum 133
)/!D )/!D PV mean value 135
)/!D6 )/!D6 Time PV above threshold level 139
)/!D: )/!D: PV threshold for timer log 138
5D) 5D) Logging reset
0: Not reset
1: Reset
140
,6 ,6 Maximum Control Task Time
(Processor utilisation factor) 201
=D0 =D0 Working output 4
5 5 PDSIO SSR status
0: Good
1: Load fail
2: Open
3: Heater fail
4: SSR fail
5: Sn fail
79
D0 D0 Feedforward component of
output 209
0 0 0 0 Proportional component of
output 214
N 0 N 0 Integral component of output 55
0 0 Derivative component of output 116
:0 :0 VP motor calibration state
0: Start
1: Waiting
2: Open valve
3: BLUp/InDn
4: Ttup
5: Overshoot
6: InUp/BLDn
7: TT down
8: Open
9: Low lim
10: Stopping
11: Raise
12: Inert up
13: Lower
14: Low lim
15: Stopping
16: Lower
17: InDn/BL
99: Abort
210
Controller I/O Tab Tag
Display Parameter Description Address
DC Output 1A Telemetry 12694
DC Output 2A Telemetry 12758
DC Output 3A Telemetry 12822
BCD Input Value 96
Controller Miscellaneous Tab Tag
Display Parameter Description Address
Instrument Mode 199
Instrument Version Number 107
Instrument Ident 122
Slave Instrument Target
Setpoint 92
Slave Instrument Ramp Rate 93
Slave Instrument Sync 94
Remote SRL Hold 95
CNOMO Manufacturers ID 121
Remote Parameter 151
Error Logged Flag 73
Ramp Rate Disable 78
Maximum Input Value 548
Minimum Input Value 549
Holdback Disable 278
All User Interface Keys Disable 279
