Tag Addresses 2408
f
& 2404
f
PROFIBUS Communications Handbook
8-4 2408
f
& 2404
f
PROFIBUS Communications Handbook
Controller
PID Tab
Tag
Display
Parameter Description
Address
!D0
!D0
Gain scheduler setpoint
153
7
7
Current PID set (read only if
gain scheduling is selected)
0: Set 1
1: Set 2
72
0
0
Proportional band PID1
6
7O
7O
Integral time PID1
0: Off
8
6
6
Derivative time PID1
0: Off
9
5
5
Manual reset PID1
28
#
#
Cutback high PID1
0: Auto
18
)
)
Cutback low PID1
0: Auto
17
5)D
5)D
Relative cool gain PID1
19
1
1
Proportional band PID2
48
6O
6O
Integral time PID2
0: Off
49
6
6
Derivative time PID2
0: Off
51
5D
5D
Manual reset PID2
50
#
#
Cutback high PID2
0: Auto
118
)
)
Cutback low PID2
0: Auto
117
5)
5)
Relative cool gain PID2
52
D1
D1
Feedforward proportional band
97
D65
D65
Feedforward trim
98
D:
D:
Feedforward trim limit
99
Controller
Motor Tab
Tag
Display
Parameter Description
Address
6,
6,
Valve travel time
21
N.D6
N.D6
Valve inertia time
123
D6
D6
Valve backlash time
124
,1D6
,1D6
Minimum pulse time
54
:D5
:D5
Bounded sensor break
strategy
128
D/1
D/1
VP Bounded sensor break
62
Controller
Setpoint Tab
Tag
Display
Parameter Description
Address
)
)
Select setpoint
0: SP1
1: SP2
15
2: SP 3
3: SP 4
4: SP 5
5: SP 6
6: SP 7
7: SP 8
8: SP 9
9: SP 10
10: SP 11
11: SP 12
12: SP13
13: SP14
14: SP15
15: SP16
)B5
)B5
Local or remote setpoint select
0: Local
1: Remote
276
1
1
Setpoint 1
24
1
1
Setpoint 2
25
1
1
Setpoint 3
164
1
1
Setpoint 4
165
0
0
Setpoint 5
166
0
0
Setpoint 6
167
0
0
Setpoint 7
168
0
0
Setpoint 8
169
0
0
Setpoint 9
170
0
0
Setpoint 10
171
0
0
Setpoint 11
172
0
0
Setpoint 12
173
0
0
Setpoint 13
174
0
0
Setpoint 14
175
0
0
Setpoint 15
176
0
0
Setpoint 16
177
5,D0
5,D0
Remote setpoint
485
5,6D6
5,6D6
Remote setpoint trim
486
57
57
Ratio setpoint
61
)/D6
)/D6
Local setpoint trim
27
0 )
0 )
Setpoint 1 low limit
112
0 #
0 #
Setpoint 1 high limit
111
0D)
0D)
Setpoint 2 low limit
114
0D#
0D#
Setpoint 2 high limit
113
)/D)
)/D)
Local setpoint trim low limit
67
)/D#
)/D#
Local setpoint trim high limit
66
055
055
Setpoint rate limit
0: Off
35
#D6@
#D6@
Holdback type for sp rate limit
0: Off
1: Low
2: High
3: Band
70
#
#
Holdback value for srtpoint
rate limit
65
Dwell Segment
62
Goto
517
Programmer State Write
57
Programmer state Read
23
