Powerline MU
Page 43 of 112
6.3 ADVANCED
6.3.1 BAM Configuration
Figure 23 BAM Configuration
Enable Authentication Mode and add one or more Authentication Server IPs to use a
bandwidth manager. Select Use Default Key to use the all zeroes key, as shown in the
screen above, or select “Use This Key” and enter a key. The Key must match the key
entered in the bandwidth manager.
64 to 64Kbps 257 to 512 -- 512Kbps 2049 to 4096 -- 4Mbps
65 to 128 -- 128Kbps 513 to 1024 --1Mbps 4097 t0 10240-- 10Mbps
129 to 256 -- 256Kbps 1025 to 2048 -- 2Mbps >10241 -- 42.5Mbps (full speed)
