62 Appendices Appendices 63
Appendix A: Specifications
USB Photo Port 1 For transfer of JPEG files only.
Audio Inputs 5
pairs
Analog left and right audio
RCA Pin Plug 500 mV (full scale), 43-k
ohm
Outputs
Description
Qty. Output Specifications
Audio Speakers 2 5.75" x 2.4"
Analog Audio
(Signal) 1
pair
RCA Pin Plug, 500 mV rms + 200 mV
(full scale) for analog sources, 1.5
Vrms + 0.5 Vrms (full scale) for digital
sources.
Digital Audio
Output 1 RCA Pin Plug, Signal Type Dolby
Digital, PCM stereo
3-D Glasses
Emitter 1 VESA 1997-11 Connector and Signal
Standards for Stereoscopic Display
Hardware
Image Technology Lamp
DLP, 0.65” chip, 1920 x 1080 pixels with Smooth
™
180-watt VIP type
Channel
Frequency
Reception Over-the-Air: VHF 2–13, UHF 14–69
Analog Cable: 1–125
Digital Cable: 1–135
Channel
Type*
Over the Air:
Analog NTSC, Digital ATSC with
sub-channels (all 18 video formats)
Cable:
Analog NTSC (non-scrambled)
Digital QAM 64 and 256 with sub-
channels (non-scrambled)
* Note for Digital Channels: The channel numbers displayed
on screen are determined by the broadcaster or cable company
and can vary from the standard frequency number. If there is no
channel-number information provided by the broadcaster or cable
company, the TV creates a channel number. The created channel
number uses the frequency number as the main channel number
and the program number as the sub-channel number.
Size, Weight, and Power Consumption
Model
Dimensions (inches)
Weight
(lbs.)
Power
(watts) Height Width Depth
WD-60735 36.7 53.8 14.4 68.3 265
WD-65735 39.5 58.2 15.4 75.4 265
WD-73C8,
WD-73735
43.6 65.2 17.5 95 265
WD-65736 39.5 58.2 15.4 75.4 270
WD-73736 43.6 65.2 17.5 95 270
WD-65835 39.5 58.2 15.4 78 270
WD-73835 43.6 65.2 17.5 98 270
Inputs
Type
Qty. Input Specifications
Antenna/Cable
input 2 RF
F connector, 75-ohm
HDMI (digital
video/audio) CEA-861D standard for digital audio
and video via HDMI
HDMI standard connector
Video:
60 Hz: 480i, 480p, 720p, 1080i
24 Hz, 30 Hz, 60 Hz: 1080p
Audio: PCM stereo
HDMI inputs are compliant with
CEA-861D standards for standard,
extended, and high-definition video;
digital audio, and HDCP copy protec-
tion.
PC (digital signals only):
VGA (640 x 480, 60 Hz)
W-VGA (848 x 480, 60 Hz)
SVGA (800 x 600, 60 Hz)
W-SVGA (1064 x 600, 60 Hz)
XGA (1024 x 768, 60 Hz)
1280 x 720, 60 Hz
SXGA (1280 x 1024, 60 Hz)
1920 x 1080 (24 Hz, 30 Hz, 60 Hz)
WXGA (1360 x 768, 60 Hz))
WD-73C8
WD-60735
WD-65735
WD-73735 3
WD-65736
WD-73736
WD-65835
WD-73835 4
Composite
Video up
to 3
NTSC 480i only
Video:
RCA Pin Plug, 1.0 V p-p,
75 ohm
1 dedicated composite video jack; 2
shared with component video Y
S-Video 1 Four-Pin DIN Plug
Y: 1.0 Vp-p 75-ohm
C: 0.286 Vp-p (burst signal), 75-ohm
Component
Video (Y/Pr/Pb) up to 3
sets
CEA-770.1 & CEA 770.2 480i, 480p,
CEA 770.3 720p and 1080i (TV
analog component video standards)
RCA Pin Plug
Y: 1.0 Vp-p (includes sync),
75-ohm
Pr: 700 mV p-p, 75-ohm
Pb: 700 mV p-p, 75-ohm
1 dedicated set of component video
jacks; 2 sets share a jack with com-
posite video
Bypassing the Parental Lock
After you set the lock, you must use your pass code
to view a locked program, view the locked TV, view
a locked channel, cancel the lock, or enter the
Lock
menus.
If you forget your pass code, you can view the locked
TV without entering your pass code. When you are
prompted for your pass code, press the number
9 and
QV keys on the TV remote control at the same time. This
process temporarily unlocks the TV.
When entering the Lock menu, this process deletes
your old pass code and prompts you to enter a new
pass code.
• You can either enter a new pass code to open the
Lock menu and make changes or press EXIT to close
the menu.
• If any of the locks are turned on and you exit the
menus when prompted for a new code, the old
code and all lock settings are retained.
• If all locks are turned off and you exit the menus
when prompted for a new code, then the previous
code is erased.
Lo
ck B
yp
as
s I
n
st
ru
ct
io
n
s H
av
e B
ee
n F
ile
d f
o
r
Fu
tu
re R
ef
er
en
ce
IMPORTANT
Cut along the dotted line and file bypass
instructions in a safe place for future
reference.
IMPORTANT
When changing or deleting your pass code,
you must use the remote control included
with this TV. You cannot use a Mitsubishi
remote control from another component or a
“universal” remote.
Appendix B: Bypassing the Parental
Lock
