APPENDIX A: Server Specifications
84
VGA connector
Serial port connector
Keyboard and Mouse connectors
Pin Signal Name
1 Red
2 Green
3 Blue
4 No connection
5 GND
6 GND
7 +5 V
8 GND
9 +5 V
10 GND
11 No connection
12 SDA
13 HSYNC (horizontal sync)
14 VSYNC (vertical sync)
15 SCL
Pin Signal Name Description
1 DCD Data Carrier Detect
2 RXDATA Receive Data
3 TXDATA Transmit Data
4 DTR Data Terminal Ready
5 GND Ground
6 DSR Data Set Ready
7 RTS Request To Send
8 CTS Clear To Send
9 RI Ring Indicate
Pin Signal Name
1 Keyboard (or mouse) data
2 NC
