Front, Control panel – Gateway E-9722R User Manual
Page 8
CHAPTER 1: Checking Out Your Gateway Server
2
Front
Control panel
Hard drives (as many as 12)
Hard drive
tray LEDs
Optical drive
SMIL module
bay (optional)
Control panel
VGA port
USB ports (2)
Power button
ID button
Power LED
ID LED
NIC status
LED
System fault LED
Reset button
NMI button
