CHAPTER 1: Checking Out Your Gateway Server
6
9 Serial port (J12) 27 Main power connector (J48)
10 PS/2 keyboard and mouse ports (J10) 28 Internal USB port for USB floppy (J59)
11 Rear dual USB Port (J6) 29 Power supply I
2
C connector (J55)
12 DIMM socket group for processor 3 (J14, J15,
J16, J18) 30 System configuration jumper (J56)
13 Processor 3 (CPU3) socket 31 Floppy connector (J40)
14 Processor 1 (CPU1) socket 32 Battery (B1)
15 Processor power connector (J1) 33 PCI-E mezzanine board connector (J38)
16 Fan tach connector (J2) 34 PCI-X mezzanine board connector (J49)
17 DIMM socket group for processor 2 (J5, J17, J8,
J9) 35 Front panel USB connector (J53)
18 Processor 2 (CPU2) socket 36 Chassis intrusion connector (J58)
# Feature # Feature
