Processor power connector (J1)
4 +5 V
5 Ground
6 +5 V
7 Ground
8 Power good
9 Stand by +5 V
10 +12 V
11 +12 V
12 +3.3 V
13 +3.3 V
14 -12 V
15 Ground
16 DC_ON (soft on/off)
17 Ground
18 Ground
19 Ground
20 Key
21 +5 V
22 +5 V
23 +5 V
24 Ground
Pin Signal Name
1 Ground
2 Ground
3 Ground
4 Ground
5 +12 V1
6 +12 V1
7 +12 V2
8 +12 V2
Pin Signal Name
