English – GIGABYTE AGP 4X(1.5V) User Manual
Page 97
Technical Reference
- 93 -
English
SPDIF Output Device (Optional Device)
3
. Connect co-axial or optical output to the SPDIF
decoder.
1
. Connect the SPDIF output device to the rear
bracket of PC, and fix it with screw.
2. Connect SPDIF wire to the motherboard.
A “SPDIF output” device is available on the
motherboard. Cable with rear bracket is provided
and could link to the “SPDIF output” connector
(As picture.) For the further linkage to decoder,
rear bracket provides coaxial cable and Fiber con-
necting port.
