Introduction - 5 -
English
Form Factor 30.5cm x 24.4cm ATX size form factor, 4 layers PCB.
Motherboard GA-8PE667 Series Motherboard:
GA-8PE667 Ultra2 and GA-8PE667 Pro
CPU Socket 478 for Intel ® Micro FC-PGA2 Pentium ® 4 processor
Intel Pentium ® 4 533MHz/400MHz FSB
Support Intel ® Pentium ® 4 (Northwood, 0.13 m) processor
Support Intel ® Pentium ® 4 Processor with HT Technology
2nd cache depend on CPU
Chipset Chipset 845PE HOST/AGP/Controller
ICH4 I/O Controller Hub
Memory 3 184-pin DDR DIMM sockets
Supports DDR333/DDR266 DDR DIMM
Supports up to 2GB DRAM (Max)
Supports only 2.5V DDR DIMM
I/O Control ITE8712
Slots 1 CNR(Communication and Networking Riser) Slot **
1 AGP slot 4X (1.5V only) device support
6 PCI slot supports 33MHz & PCI 2.2 compliant
On-Board IDE 2 IDE controllers on the Intel ICH4 PCI chipset
provides IDE HDD/CD-ROM (IDE1, IDE2) with PIO, Bus Master
(Ultra DMA33/ATA66/ATA100) operation modes.
IDE3 and IDE4 Compatible with RAID,Ultra ATA133/100.**
On-Board Peripherals 1 Floppy port supports 2 FDD with 360K, 720K,1.2M, 1.44M
and 2.88M bytes.
1 Parallel port supports Normal/EPP/ECP mode
2 Serial ports (COMA & COMB)
6 USB 2.0/1.1
(2 port rear,4 ports by cable)
1 IrDA connector for IR/CIR
1 Front Audio connector
Chapter 1 Introduction
to be continued......
Features Summary
Due to (Intel 845PE/GE/GV) chipset architecture limitation, DDR 333 memory module is
only supported when using FSB 533 Pentium 4 processor. A FSB 400 Pentium 4 processor
will only support DDR 266 memory module
* For GA-8PE667 Pro Only ** For GA-8PE667 Ultra2 Only
