Troubleshooting
If you encounter any trouble during boot up, please follow the
troubleshooting procedures .
Turn off the power and unplug the AC power cable, then
remove all of the add-on cards and cables from motherboard.
START
Failure has been excluded.
Yes
Please make sure motherboard & chassis are not short
?
No
A
Please make sure all jumper settings (such as CPU system bus
speed, frequency ratio, voltage and etc.) are set properly.
Failure has been excluded.
Check if the CPU cooling fan attached to CPU properly. ls
CPU cooling fan power connected to CPU_FAN
properly?
Plug the CPU
cooling fan power
in the CPU fan
connector. Plug in
the AC power
connector.
Check if the memory install properly into the DIMM slot.
Yes
No
Yes
Insert and push
the memory
module vertically
into the DIMM slot.
Insert the VGA card. Then plug in ATX power cable and
turn on the system.
No
No
Yes
Failure has been excluded.
Failure has been excluded.
Please isolate
the short pin.
Make sure the
jumper setting
are correct.
