English – GIGABYTE AGP 4X(1.5V) User Manual
Page 30
- 26 -
GA-8PE667 Ultra2 / Pro Motherboard
English
13)PWR_LED
PWR_LED is connect with the system power indicator to indicate whether the system is on/off. It
will blink when the system enters suspend mode. If you use dual color LED, power LED will turn
to another color.
1
Pin No. Definition
1
MPD+
2
MPD-
3
MPD-
8)2X_DET
When an AGP 2X (3.3V) card is installed the 2X_DET will light up, indicating a
nonsupported graphics card is inserted. Informing users that system might not boot
up normally due to AGP 2X (3.3V) is not supported by the chipset.
+
-
