Page 5
PBT-860BS-B
PBT-860BS-G
PBT-860BS-R
22mm
Free Position
Operation Position
Operating travel:
2.7mm
Materias: Zinc alloy
Momentary (N/O,N/C,Com) Double Pole Double Throw
Switch Rating : 5A/125 VAC
Contact resistance: 50mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7mm
2.0
21.0
M22 x P1.5mm
0.6mm
thickness
2.0
5
24.5
85.0
You can use the push button
at any angle.
PBT-863BS-B
PBT-863BS-G
PBT-863BS-R
PBT-861BS-B
PBT-861BS-G
PBT-861BS-R
PBT-864BS-B
PBT-864BS-G
PBT-864BS-R
PBT Exit Button
British Size Faceplate
