Gianni Industries PBT-425BS - Manual (Page 4)

PBT-450BS
PBT-451BS
PBT-452BS
PBT-453BS
PBT-454BS
PBT-455BS
40.0
10.5
23.0
M22 x P1.5mm
0.6mm
thickness
2.0
5 50.0 24.5
(SWH-250)
You can use the push button
at any angle.
Free Position
Operation Position
Operating travel:
2.7mm
Material: Zinc alloy
Momentary (N/O,N/C) Double Pole Double Throw
Switch Rating : 5A/125 VAC
Contact resistance: 50mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.7mm
22mm
PBT Exit Button
British Size Faceplate
