g0649 Welding downdraft table
-3-
MODEL G0649
LARGE DOWNDRAFT TABLE
Customer Service #: (570) 546-9663 • to order Call: (800) 523-4777 • Fax #: (800) 438-5901
MACHINE DATA
SHEET
Product Dimensions:
Weight ............................................................................................................................................................................ 750 lbs
Width/depth/height ...................................................................................................................................54
13
⁄
16
" x 39
7
⁄
16
" x 73"
Foot print (length/Width) ....................................................................................................................................54
13
⁄
16
" x 39
7
⁄
16
"
Shipping Dimensions:
type ...................................................................................................................................................................................Crate
Content .......................................................................................................................................................................... Machine
Weight ............................................................................................................................................................................ 794 lbs.
length/Width/height ....................................................................................................................................57
1
⁄
2
" x 43
5
⁄
16
" x 50"
Electrical:
Switch ....................................................................................................................................................................Control panel
Machine Voltage ..................................................................................................................................................220V 3-phase
Cord gauge .................................................................................................................................................................. 14 aWg
Minimum Circuit Size ......................................................................................................................................................20 amp
included plug ......................................................................................................................................................................... no
Motors:
Main
type ..........................................................................................................................................................tEFC induction
horsepower ............................................................................................................................................................1.5 hp
Voltage ..................................................................................................................................................................... 220V
phase ...................................................................................................................................................................... three
amps ............................................................................................................................................................................ 5a
Speed ...............................................................................................................................................................1725 rpM
Cycle ........................................................................................................................................................................ 60 hz
number of Speeds ............................................................................................................... Variable Fan Speed Control
Filter roller Motor
power .......................................................................................................................................................................... 3W
Voltage ..................................................................................................................................................................... 110V
Cycle .................................................................................................................................................................... 50/60hz
Speeds ............................................................................................................................................................................1
Filter Vibrating Motor
power ........................................................................................................................................................................ 25W
Voltage ..................................................................................................................................................................... 220V
Cycle ......................................................................................................................................................................... 60hz
Speeds ............................................................................................................................................................................1
rpM ...........................................................................................................................................................................3200
Model G0649
