g0649 Welding downdraft table
inventory
the following is a description of the main compo-
nents shipped with your machine.
note: If you can't find an item on this list, check
the mounting location on the machine or examine
the packaging materials carefully. Occasionally
we pre-install certain components for shipping
purposes.
crate 1 & 2: (figures 3 & 4) Qty
A. Welding downdraft table unit .................... 1
b. rear panel.................................................. 1
c. hinged left & right Side panels .......... 1 Ea
D. lamp assembly .......................................... 1
E. Shelf assembly ........................................... 1
f. lamp hanger.............................................. 2
G. door handle ............................................... 2
h. top panel ................................................... 1
i. Bolt Bag ..................................................... 1
—hex Bolts 5 /
16
-18 x 3 /
4
" (panels) ............ 29
—Flat Washers 5 /
16
" (panels) ................... 29
figure 3. Welding downdraft table unit.
if any nonproprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
figure 4. accessories.
SuffOcATiOn hAzARD!
immediately discard all plastic
bags and packing materials to
eliminate choking/suffocation
hazards for children and
animals.
