2-4
CHAPTER 2
port, one parallel printer port, as well as two antennas on
the rear panel.
z
Three RJ-45 ports for connection to a 10BASE-
T/100BASE-TX Ethernet Local Area Network (LAN).
These ports can auto-negotiate the operating speed to
10/100 Mbps, the mode to half/full duplex, and the pin
signals to MDI/MDI-X (i.e., allowing these ports to be
connected to any network device with straight-through
cable). These ports can be connected directly to a PC or to
a server equipped with an Ethernet network interface card,
or to a networking device such as an Ethernet hub or
switch.
z
One RJ-45 port for connection to an xDSL or Cable
modem. This port is fixed at 10 Mbps, full duplex.
z
One RS232 serial port to connect to an ISDN Terminal
Adapter (TA) or to a PSTN analog modem.
z
One parallel printer port that can be connected to a printer,
which can be shared by any LAN/WLAN users.
z
Two antennas.
The following figure shows the components of the
Gateway:
