Gianni Industries PBT-025-4 - Manual (Page 2)

PBT-020-2
Stainless steel faceplate
PBT-200-2
Stainless steel faceplate
27mm
3mm
22mm
2.0
2mm
Free Position
Operation Position
M19 x P0.75mm
Materials (Button): Copper alloys
Max. Rating : 3A/125VAC, 6A/24VDC
Contact resistance: 50 mΩ Max.(initial)
Operating life(Mechanical) : Over 100,000 times
Operating travel: 2.0 mm
Momentary normal open (N.O.)
(SWH-CN020)
Switch Specification
Switch Specification
19 mm
19 mm
37
37
87
87
4
4
43
115
19 mm
PBT-025J
Aluminum alloy faceplate
PBT-026J
Aluminum alloy faceplate
PBT-200J
Stainless steel faceplate
43
115
19 mm
17.5
14.0
8.0
22
1.0
0.5mm thickness
M19 x P1.0 mm Free Position
Operation Position
1.75
Operating travel: 1.75mm
(MSW-1902-EXIT)
19 mm
43
115
4
Material: Stainless steel
Momentary Single pole single throw (N.O.)
Contact resistance: 1kΩ Max.(initial)
Operating life(5mA/5VDC) : Over 100,000 times
Operating travel: 1.75mm
Max. Ratings : 5mA/12VDC
Optional Accessory
SMB-040
The can be surface mounting
with SMB-040 housing.
PBT-010, PBT-020, PBT-025
GIANNI INDUSTRIES, INC.
PBT Exit Button
Special size Faceplate Series
Copyright © Gianni Industries, Inc. All rights reserved.
DM-CA-PBT-Special Ver. G Published on 2010.03.26 No. 13, Zhongxing Rd., Tucheng Dist., New Taipei
City 236,Taiwan (R.O.C.)
Tel: 886-2 2267 7986 / Fax: 886-2 2267 9876
E-Mail: [email protected]
Website: gianni.tw
