Software Functional Overview
FIC A360 Service Manual
3-5
VESA Mode Pixel Resolution Memory Model Refresh Rates In
(Hz)
Minimum
Memory
100h 640 x 400 8-bit Packed 70 2MB
101h 640 x 480 8-bit Packed 60, 72, 75, 85 2MB
102h 800 x 600 4-bit Planar 60, 72, 75, 85, 100 2MB
103h 800 x 600 8-bit Packed 60, 72, 75, 85, 100 2MB
104h 1024 x 768 4-bit Planar 43(I), 60, 70, 75, 85,
100 2MB
105h 1024 x 768 8-bit Packed 43(I), 60, 70, 75, 85,
100 2MB
106h 1280 x 1024 4-bit Planar 43(I), 60, 75, 85 2MB
107h 1280 x 1024 8-bit Packed 43(I), 60, 75, 85 2MB
10Eh 320 x 200 16-bit Packed 70 2MB
10Fh 320 x 200 32-bit Unpacked 70 2MB
111h 640 x 480 16-bit Packed 60, 72, 75, 85 2MB
112h 640 x 480 32-bit Unpacked 60, 72, 75, 85 2MB
114h 800 x 600 16-bit Packed 60, 72, 75, 85, 100 2MB
115h 800 x 600 32-bit Unpacked 60, 72, 75, 85, 100 2MB
117h 1024 x 768 16-bit Packed 43(I), 60, 70, 75, 85,
100 2MB
118h 1028 x 768 32-bit Unpacked 43(I), 60, 70, 75, 85,
100
4MB
11Ah 1280 x 1024 16-bit Packed 43(I), 60, 75, 85 4MB
11Bh 1280 x 1024 32-bit Unpacked 43(I), 60, 75, 85 8MB
11Dh 640 x 400 16-bit Packed 70 2MB
11Eh 640 x 400 32-bit Packed 70 2MB
120h 1600 x 1200 8-bit Packed 48(I), 60, 75, 85 2MB
122h 1600 x 1200 16-bit Packed 48(I), 60, 75, 85 4MB
124h 1600 x 1200 32-bit Unpacked 48(I), 60, 75, 85 8MB
12Ah 640 x 480 24-bit Packed 60, 72, 75, 85 2MB
12Bh 800 x 600 24-bit Packed 60, 72, 75, 85, 100 2MB
12Ch 1024 x 768 24-bit Packed 43(I), 60, 70, 75, 85,
100 4MB
12Dh 1280 x 1024 24-bit Packed 43(I), 60, 75, 85 4MB
12Eh 320 x 200 8-bit Packed 70 2MB
131h 320 x 200 8-bit Packed 72 2MB
133h 320 x 200 16-bit Packed 72 2MB
134h 320 x 200 32-bit Packed 72 2MB
13Bh* 1400 x 1050 8-bit Packed 60, 75 2MB
13Ch* 1400 x 1050 16-bit Packed 60, 75 4MB
13Eh* 1400 x 1050 32-bitUnpacked 60, 75 8MB
