Outline of the A360
FIC A360Service Manual 1-9
Icon Represents Indicates
n IDE Drive
Access
This LED will turn on when the system is accessing the hard
disk drive (HDD) or CD-ROM / DVD-ROM / CD-RW.
o Diskette Drive
Access
This LED will turn on when the system is accessing the floppy
disk drive (FDD).
p Caps Lock This LED will turn on when the Caps Lock key is activated.
When activated, all alphabet keys typed in will be in upper
case or in capital letters.
q Scroll Lock This LED will turn on when the Scroll Lock key is activated.
r Num Lock This LED will turn on when the Num Lock key is activated.
When activated, the embedded numeric keypad (blue print
numeric keys) will be enabled.
Keyboard Panel
− Standard QWERTY-key layout and full-sized 87/90 keys keyboard with Windows
hot-keys, embedded numeric keypad, hot keys, inverted “T” cursor arrow keys,
and separate page screen control keys.
− Wide extra space below the keyboard panel for your wrist or palm to sit-on
comfortably during typing. (The keypad F4, F5, F7 on the following keyboard
should no words print on it.)
n Function Keys o/q Control Keys p Windows Start Menu Key
r Windows Short-cut Key s Cursor Control Keys
Figure 1-6 Keyboard Layout
The notebook keyboard is a little bit different from a standard desktop keyboard. Aside
from the normal alphanumeric characters and the standard keyboard function keys, the
notebook keyboard includes an embedded numeric keypad, and special function keys that
activates by pressing the <Fn> key together with another key. These special function keys
or “hot-keys” allow you to control and adjust some of the functions of the notebook like
display controls, power saving features, and others.
(1) Function Keys — These function keys, out of
through , are available on
the notebook keyboard. These keys also work together with the key to activate
special functions. The following function-key combinations are pre-programmed:
