Outline of the A360

FIC A360Service Manual

1-25

Parallel port

[Disabled] / [Auto] /
[Enabled]

Configure parallel port using options:

Disabled - No configuration,

Enabled - User configuration,

Auto - BIOS or OS configuration.

Mode

[ECP] / [EPP] /
[Uni-directional]

Set the mode for the parallel port using
options: Uni-directional, EPP, and ECP

Base I/O address

[378] / [278] / [178]

Select the base I/O address for the parallel
port when port is Enabled.

Floppy disk
controller

[Disabled] / [Enabled]

Configure the floppy disk controller using
options:

Disabled - No configuration,

Enabled - User configuration

If you disable a device in BIOS Setup, you cannot enable or assign it using the
Windows (98 or 2000) Device Manager. The device is not listed in the Windows
device list. You need to select any setting other than “Disable” in Setup.

Serial Port

A – You can press <Enter> to select Enabled, Disabled, or Auto

option for enabled or disabled this port, or automatically sensed the address
assignment by BIOS or OS. When you set the configured parallel port to Enabled
rather than Auto, you should also set the parameter of Base I/O address for this port.

Infrared Port

– You can press <Enter> to select Enabled, Disabled, or Auto

Parallel Port

– Allows you to press <Enter> to select the Enabled, Disabled,

or Auto option for enabled or disabled this port, or automatically sensed the address
assignment by BIOS or OS.

Mode

– Allows you to press <Enter> to select a parallel mode as Uni-directional,

EPP, or ECP when the parallel port is configured. When you set the configured
parallel port to Enabled rather than Auto, you should also set the parameter of Base
I/O address for this port.

Floppy Disk Controller

–Allows you to press <Enter> to select the

Enabled or Disabled option for configured or not configured the floppy disk
controller.
