Maintenance & Disassembly
5.5.12 Removing / Replacing the Motherboard
The motherboard contains the major chipset and components needed to run the notebook.
Follow the steps below on how to remove and replace the motherboard:
1. Before removing the motherboard, you need first to disassemble the all basis unit
modules mentioned in the previous sections.
2. On the motherboard, there are ten hex bolts and two screws as showed below. Remove
these hex bolts and screws.
Six Hex bolts at Rear Side of Notebook
Screws
Hex bolts
Lid Switch
Figure 5-18 Motherboard Screws Location
3. Detach the lid switch cable connected to the main board
4. When all screws ,bolts, and lid switch cable are removed, slowly detached the main board
from the base unit casing. Notice the close gap between the volume control knob and
button case and may use the specific tooling to separate them more easily.
