background image

Pin Assignments

4

CLK

SMBus clock signal

I/O

5

DTA

SMBus data signal

I/O

6 TH1

THERMAL

O

7 BIN1

O

8 GND

GROUND

-

B.13 Audio Jack

The audio jack comprises of the headphone jack, line-out jack, and microphone jack:

SPDIF & Headphone Jack

The pin assignment of the headphone jack is as follows:

No Signal Description

Type

4 GND

Ground

I

2

HP_L

Headphone left sound

O

3

HP_R

Headphone right sound

O

5

SPDIFDET

SPDIF insert detect

I

1

HPDET

Headphone insert detect

I

8

SPDIF PWR SPDIF power

O

7 SPDIF

SPDIF

signal

O

9 GND

Ground

I

Line-In Jack

The pin assignment of the line-in jack is as follows:

No Signal Description

Type

1 GND

Ground

I

2

LINEINL

Line in left sound

I

3

LINEINR

Line in right sound

I

4 GND

Ground

I

5 GND

Ground

I

Microphone Jack

The pin assignment of the microphone jack is as follows:

No Signal Description

Type

1 GND

Ground

I

2

MICIN

External Microphone input signal

I

3 GND

Ground

I

4

EXTMICDET EXTERNAL MIC detect

I

5 GND

Ground

I

B.14 Internal Microphone Connector

The pin assignment of the internal microphone is as follows:

No Signal

Description

Type

1

MICIN

External Microphone input signal

2 GND

Ground
