background image

4.6 Read/write Circuit

C141-E104-02EN

4-11

4.6.2 Write circuit

The write data is output from the hard disk controller (HDC) with the NRZ data
format, and sent to the encoder circuit in the RDC. The NRZ write data is
converted from 16-bit data to 17-bit data by the encoder circuit then sent to the
HDIC, and the data is written onto the media.

(1) 16/17 MTR MEEPRML

This device converts data using the 16/17 MTR (Maximum Transitions Run
Length Limited) algorithm.

This code is converted so that a maximum of three 1’s are placed continuously
and so that there are two or fewer 1’s in a 17-bit border.

(2) Write precompensation

Write precompensation compensates, during a write process, for write non-
linearity generated at reading. Table 4.2 shows the write precompensation
algorithm.

Table 4.2 Write precompensation algorithm

Bits

Compensation

111001

111010

:

111111

000000

000001

:

010000

:

100000

–7

–6

–1

±

0

+1

+16

+32
