Installation Conditions
3-8 C141-E104-02EN
(5) Service area
Figure 3.6 shows how the drive must be accessed (service areas) during and after
installation.
Figure 3.6 Service area (Sample: MHL2300AT)
CAUTION
Data corruption: Avoid mounting the disk drive near strong
magnetic sources such as loud speakers. Ensure that the disk drive
is not affected by external magnetic fields.
Damage: Do not press the cover of the disk drive. Pressing it too
hard, the cover and the spindle motor contact, which may cause
damage to the disk drive.
Static: When handling the device, disconnect the body ground
(500 k
Ω
or greater). Do not touch the printed circuit board, but
hold it by the edges.
(6) Handling cautions
Please keep the following cautions, and handle the HDD under the safety
environment.
Mounting screw hole
Mounting screw hole
Cable connection
