1.3 Power Requirements
C141-E104-02EN 1-5
Under the CHS mode (normal BIOS specification), formatted capacity,
number of cylinders, number of heads, and number of sectors are as
follows.
Table 1.1 Specifications (2/2)
Model Capacity No. of Cylinder No. of Heads No. of Sectors
MHL2300AT 8.45 GB 16,383 16 63
MHM2200AT 8.45 GB 16,383 16 63
MHM2150AT 8.45 GB 16,383 16 63
MHM2100AT 8.45 GB 16,383 16 63
1.2.2 Model and product number
Table 1.2 lists the model names and product numbers of the MHL Series and
MHM Series.
Table 1.2 Model names and product numbers
Model Name Capacity
(user area)
Mounting screw Order No.
MHL2300AT 30 GB M3, depth 3 CA05428-B061
MHM2200AT 20 GB M3, depth 3 CA05429-B041
MHM2150AT 15 GB M3, depth 3 CA05429-B031
MHM2100AT 10 GB M3, depth 3 CA05429-B021
1.3 Power Requirements
(1) Input Voltage
• + 5 V ± 5 %
(2) Ripple
+5 V
Maximum 100 mV (peak to peak)
Frequency DC to 1 MHz
